essenza idra 18 EVO stone

Pellet Thermostove
Pellet stove with an essential and minimalist design, clad in soapstone or coloured steel embellished with aromatic essential oils. Equipped with the motorised fan technology PELLETPOWER® (Idra model) heat exchanger THERMOCORE® and simplified cleaning system EASY CLEANING. Available in versions, Silent, Air, Plus and Idra.
Heatable area
160 m².

thermorossi_aromy_stone_numbers

1 - Programming control panel
2 - Glass top plate
3 - Precious ceramic handle with aroma diffusor
4 - Sliding top access to the pellet tank
5 - Soapstone
6 - Cast iron and glass inlayed firebox door

Every uniti s tested for one hour in the factory Our products don’t incur additional cost for adjustments or testing Simplified cleaning system Heat exchanger Thermocore® Low energy consumption Higher heat accumulation only 36 decibels of noise Smart info Pelletpower® - Patented burner External primary air input Madaly

OPTIONAL ACCESSORIES

  • INTEGRA TR-PACK
  • I control
  • room control


DIMENSIONS

essenza idra 18 stone

TECHNICAL DATA

DIMENSIONS (HXWXD)    1132x518x596
WEIGHT (kg)    213.5
HEATABLE AREA (m²)    160
EFFICIENCY UP TO MAX (%)    96,7%
ENERGY CLASS (SCALE A++/G)    A+
POWER TO THE HEART (kW)    5,3 - 18,9
RATED POWER (kW)    5,1 - 17,8
POWER TO THE WATER (kW)    3,8 - 15,0
RADIATION (kW)    1,3 - 2,8
HOURLY PELLET CONSUMPTION (kg/h)    1,1 - 3,9
WOOD HOURLY CONSUMPTION (kg/h)V     -
PELLET HOPPER CAPACITY (kg)    22,00
WARM AIR DUCTING    -
MAXIMUM SINGLE DUCTING OUTLET (m)    -
PATENTED BURNER PELLETPOWER®    SI
ROMM VENTILATION    -
PRIMARY AIR FROM OUTSIDE    SI
CO EMISSIONS (mg/m³; 13% di O2)    46
CO EMISSIONS (mg/m³; 10% di O2)    -
DUST EMISSIONS (mg/m³; 13% di O2)    13
DUST EMISSIONS (mg/m³; 10% di O2)    -
SILENCE(dB)    36,00
WEEKLY PROGRAMMER (3 DAILY LIGHTING)    SI
SMART INFO FUNCTION    SI
SYSTEM CIRCULATING PUMP    SI
EXPANSION TANK    SI
OVER PRESSURE VALVE    SI
FLUE GASEXHAUST DIAMETER (mm)    100
MIN. FLUE DRAUGHT PRESSURE (Pa)    10
ELECTRIC CONSUMPTION (Watt)    35-330
HIGH TEMPERATURE SAFETY THERMOSTAT    SI
